Package includes contoured
neoprene carrying strap, front lens caps, eypiece caps, battery, Cordura case
Magnification 10 x
Front lens diameter 42
mm
Exit pupil 4.2
mm
Twilight factor 20.5
Field of view at 1,000 yds/m 374 ft / 114 m
Close focus range approx.
16.5 ft / 5.0 m
Diopter compensation ±
4 dpt
Distance measurement Range
10 yds to approx. 2,200 yds / 10 m to approx. 2,000 m
Equivalent horizontal range (EHR)
10 yds to 1.200 yds / 10 m to 1,100 m
Measuring accuracy
± 1 yd / m to 547 yds / 500 m
± 2 yds / m to 1,094 yds / 1,000 m
± 0,5 % beyond 1,094 yds / 1,000 m
Display LED display
with 4 characters and ambient-light-controlled brightness
Eyecup with twist-and-pull action yes, detachable, with 4 click-stops
Eyepieces for eyeglass wearers yes
Focusing internal
focusing with center focusing barrel
Prism system Perger
Porro-System
Coating HDC®
multicoating, AquaDura® lens coating
Waterproof waterproof
to 16.5 ft / 5 m
Body aluminium,
nitrogen-filled
Dimensions (W x H x D) 4.9
x 7.0 x 2.8 in / 125 x 178 x 70 mm
Weight approx. 33.3 oz
/ 980 g incl. battery
Yard/Meter switch yes
Laser eye-safe,
invisible light laser compliant with EN and FDA Class 1
Measuring mode scan
mode, single measurement
Ballistic system yes,
equivalent horizontal distance, range ballistic function up to 600 yds/550 m
Power supply 1 x 3
V/ CR2 lithium button cell
Battery life approx.
2,000 measurements at 68° F / 20°C
Accessories tripod
adapter (42 220)
floating carrying strap (42 163)
