Magnification
2x
Palettes
Black Hot, White Hot, Red Hot, Fusion
Reticle
5 types, 4 colors, on/off
Drop Test Height
1.5m (4.9 feet)
Boresight Adjustment
Digital Controlled
Distance Measurement
Yes (Stadiametric Rangefinder)
Scene Mode
Jungle, Recognition
Picture In Picture Mode (PIP)
Yes (2× Zoom)
Video Recording
Yes
Defective Pixels Correction (DPC)
Yes
Uniformity Correction
Auto, Manual, External Correction
Digital Magnification
2x - 16x
Detector type
12μm, Uncooled, 50 Hz
Standby Mode
Yes
Resolution
640 × 512
Detection Range (6' object)
1,750m/yd
Lens system
35 mm; F/1.0
Field of view (H × X)
12.5° × 10.0°
Digital zoom
1×, 2×, 4×, 8×
Eye relief
45 mm
Display
0.39-inch, OLED, 1024×768, 50 Hz
Storage
Built-in EMMC (16 GB)
Battery Type
Two CR123 (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries
CVBS Output
Yes (via USB)
Battery Life (Operating)
Up to 4.5 hr
External power supply
5 VDC/2 A, USB Type-C interface
Operating Temperature Range
-20°C to +55°C (-4°F to +131°F)
Degree of Protection
IP67
Weight
535 g (1.18 lb)
Overall Dimensions
187× 63 × 80 mm (7.4 × 2.5 × 3.1 in)
Package Includes
Thermal Imaging Rifle Scope, Mount, USB Cable, Lens Cloth, Manual
|
