Palettes
Black Hot, White Hot, Red Hot, Fusion
Reticle
5 types, 4 colors, on/off
Boresight Adjustment
Digital Controlled
Boresight Increment
0.09 mil / 0.31 MOA
Distance Measurement
Yes (Stadiametric)
Scene Mode
Jungle, Recognition
Picture In Picture Mode (PIP)
Yes
Video Recording
Yes
Defective Pixels Correction (DPC)
Yes
Uniformity Correction
Auto, Manual, External Correction
Digital Magnification
4x - 32x
Detector type
12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0)
Standby Mode
Yes
Resolution
384 × 288
Detection Range (6' object)
2600 m/yd
Snapshot
Yes
Lens system
50 mm; F/1.0
Field of view (H × X)
5.4° × 4.0°
Digital zoom
1×, 2×, 4×, 8×
Diopter adjustment range
-5 to +5 dpt
Eye relief
≥ 60 mm
Display
1024×768, 50 Hz, OLED
Battery Type
Two 18650 Rechargeable Batteries (built-in) and one CR123 Battery
Wi-Fi
Yes
CVBS Output
Yes (via USB)
Battery Life (Operating)
Up to 15 hr
Power supply
5 VDC/2 A, USB Type-C Supports QC3.0
Degree of Protection
IP67
Weight
970 g ( 2.14 lb)
Overall Dimensions
420 × 78 × 82 mm (16.5 × 3.1 × 3.2 in)
Magnification
4×
|
